Why securing Microsoft Graph Command Line Tools matters
B
Ben Roberts

A blog for all things Azure! Whether you're a developer or IT pro, explore tips, trends, and hands-on guides to optimize and transform your workflow with Microsoft Azure's powerful capabilities. Join me while I learn new features and technologies from code to infrastructure.

Graph PowerShell is one of the most convenient ways to work with Microsoft Graph. It's also one of the easiest ways to accidentally expand what a user can read or change across your tenant.

If you've ever run Connect-MgGraph, signed in successfully, and still hit "Insufficient privileges", you're in good company. The missing piece is usually that delegated permissions are not just about "your user" or "the cmdlet" - they're about the combination of:

  • the client application you're signing in with (for Graph PowerShell default sign-in, "Microsoft Graph Command Line Tools"), and

  • the user who signed in.

Once you keep those two things together, the whole delegated permission story gets more predictable. And once you factor security into that model, it gets obvious why "Microsoft Graph Command Line Tools" is worth treating like a privileged admin tool in your tenant.

Connect-MgGraph uses a client application context to request tokens. When you authenticate with Graph PowerShell using the default client app, the Entra sign-in is recorded under the enterprise application named Microsoft Graph Command Line Tools.

Here's the security punchline: if you grant admin consent for high-privilege delegated scopes to Microsoft Graph Command Line Tools, you're not granting those scopes to "a script" - you're granting them to a client app that any allowed user can sign into.

That means a user with no Entra ID admin roles can still perform tenant-wide operations that are outside the "standard user" experience if:

  • the delegated scope is tenant-wide (example: directory-wide read), and

  • Graph doesn't require an admin role for that specific operation, and

  • your tenant policies don't block it.

For example, if an admin grants admin consent for User.Read.All and/or Group.Read.All to Microsoft Graph Command Line Tools, a standard user can request those scopes and enumerate users/groups. This allows any employee to download your entire corporate directory (names, emails, job titles) for phishing reconnaissance, which is normally blocked for standard users in many enterprise organizations.

Connect-MgGraph -Scopes "User.Read.All","Group.Read.All"
Get-MgUser -All | Select-Object DisplayName, UserPrincipalName
Get-MgGroup -All | Select-Object DisplayName, Id

This doesn't "bypass roles" in general (many endpoints still require specific Entra roles), but it can expand what non-admin users can read through Graph PowerShell if tenant-wide read scopes are admin-consented to the client app.

For write operations, Graph enforces both the delegated scope in the token and the signed-in user's authorization for that specific action (for example, group membership changes require a write scope and the caller being allowed to manage the group). That's exactly why "who can use the client app" is such an important control.

And it isn't just read access. If you admin-consent tenant-wide write scopes (for example, GroupMember.ReadWrite.All or Directory.ReadWrite.All) to Microsoft Graph Command Line Tools, any user who can sign into the app can request those scopes and attempt write operations from PowerShell. Each request still has to pass Graph's authorization checks (scope + user privilege + policy), but you have increased the population of users who can request and present those scopes to Graph.

The mental model (three actors)

Every delegated call to Microsoft Graph has three actors involved:

  • Resource API: Microsoft Graph (the API you're calling)

  • Client app: Microsoft Graph Command Line Tools (the Entra ID application context Connect-MgGraph uses by default)

  • User: the identity that signed in

Delegated permissions are always "app + user". That's not a philosophical point - it's how Entra ID issues tokens and how Graph authorizes requests.

Why the client app name matters ("Microsoft Graph Command Line Tools")

When you run Connect-MgGraph, you're not just "signing into Graph". You're signing into a client application that requests Microsoft Graph scopes on your behalf.

So when you grant/admin-consent delegated permissions, you're granting them to Microsoft Graph Command Line Tools (the Enterprise application / service principal in your tenant). If you grant permissions to some other app registration, but still authenticate with the Command Line Tools app, nothing changes for your Connect-MgGraph session.

If you intentionally authenticate using a different client app context (for example, your own app registration), then the permissions need to be granted to that client instead. The key idea is: permissions follow the client app that requested the token.

If you want to see this object in the UI, look in the Entra admin center under Enterprise applications for "Microsoft Graph Command Line Tools".

Delegated permissions, in one sentence

Delegated permissions are OAuth scopes that describe what the client app is allowed to do in Microsoft Graph on behalf of the signed-in user.

What Connect-MgGraph is actually doing

At a high level, Connect-MgGraph:

  1. Signs you in (interactive or device code)

  2. Requests one or more scopes

  3. Receives an access token for Microsoft Graph

  4. Uses that token on every subsequent Graph request

That access token includes (among other things) the scp claim: a space-separated list of delegated scopes that were actually granted. Graph checks those scopes at request time.

Here are two practical commands I use constantly:

Connect-MgGraph -Scopes "User.Read.All","Group.Read.All"
Get-MgContext | Select-Object -ExpandProperty Scopes

Requested vs granted vs effective (where most confusion lives)

There are three different "levels" of permission to keep straight:

  • Requested scopes: what you ask for in Connect-MgGraph -Scopes ...

  • Granted scopes: what Entra ID is willing to issue in the token (based on consent)

  • Effective access: what you can actually do in Graph, after Graph also considers the signed-in user's roles/privileges and any tenant policies

This is why two people can run the same cmdlet with the same -Scopes list and get different results: the user context still matters in delegated flows.

Consent answers a simple question: "Is this client application allowed to have this scope in this tenant?"

In most tenants:

  • Some low-impact scopes can be granted by user consent (if user consent is enabled and the permission is eligible for user consent)

  • Many org-wide or sensitive scopes require admin consent

And again, the consent is tied to the client app. When you use Connect-MgGraph with the default client app, that means the consent is tied to the Microsoft Graph Command Line Tools Enterprise application in your tenant.

From a security perspective, it's useful to say it more bluntly:

  • Admin consent is a tenant-wide decision about an application.

  • Once a delegated scope is admin-consented for Microsoft Graph Command Line Tools, the remaining question becomes: "Which users are allowed to sign into this app and request that scope?"

Gotcha: "I added permissions in Entra but it still fails"

If you added delegated permissions to a custom app registration, but you're authenticating with Connect-MgGraph using the default client app, your token request is still coming from Microsoft Graph Command Line Tools.

In that situation, you need to either:

  • grant/admin-consent the required scopes to Microsoft Graph Command Line Tools, or

  • authenticate with your custom app registration (so the token request comes from that client instead)

Another gotcha: "I made them User (or Group) Administrator, so why don't they have User.ReadWrite.All / Group.ReadWrite.All?"

This one is extremely common when people are new to Graph PowerShell.

Giving a user an Entra built-in role like User Administrator or Groups Administrator changes what that user is allowed to do in the directory. It does not magically add delegated Graph scopes to your Connect-MgGraph session.

Think of it like two separate gates you have to pass through:

  1. Scopes gate (delegated permissions): the access token must contain the delegated scope (like User.ReadWrite.All), and that scope must be consented for the client app (Microsoft Graph Command Line Tools when using the default client app).

  2. Privilege gate (who the user is): the signed-in user still needs the right admin role/privileges to perform the action.

So yes: assigning User Administrator might be necessary for certain user-management operations, but it is not sufficient. If your token only has User.Read (the default in many examples), Graph will still block write operations because the scope isn't there.

Scenario: Directory.ReadWrite.All is admin-consented, but the user has no admin roles. Can they create a group?

This scenario shows why admin consent and role assignment are separate controls.

Setup:

  • An admin has granted admin consent for Directory.ReadWrite.All to Microsoft Graph Command Line Tools.

  • The user has no admin roles assigned.

What still trips people up (and how to verify it)

Even with admin consent in place, the user still needs that delegated permission to be available in the client app + user context. In practice, once broad delegated scopes have already been consented to Microsoft Graph Command Line Tools, later Connect-MgGraph sessions can continue to surface those previously granted scopes in the session context, even if you specify a narrower -Scopes list or omit -Scopes entirely.

Disconnect-MgGraph
Connect-MgGraph -Scopes "Directory.ReadWrite.All"
Get-MgContext | Select-Object -ExpandProperty Scopes

If Get-MgContext doesn't show Directory.ReadWrite.All, any directory write call will fail regardless of the user's role.

Concrete example: can they run New-MgGroup?

Yes, if both gates are satisfied:

  1. Scope gate: the token contains a write scope that covers groups (commonly Group.ReadWrite.All or Directory.ReadWrite.All).

  2. Privilege/policy gate: the user is allowed to create the type of group you're creating (tenant settings can restrict group creation).

With Directory.ReadWrite.All in the token, Graph has the scope it needs for a group create request. The request will still fail if group creation is restricted by tenant policy for that user (for example, Microsoft 365 group creation restrictions).

Why Directory.ReadWrite.All still isn't "everything"

Even when it's granted and present in the token, Directory.ReadWrite.All doesn't replace other Graph permission families, and it doesn't override the user's role requirements. For example, these require different delegated scopes (and often different Entra roles too):

  • Conditional Access changes: Policy.ReadWrite.ConditionalAccess + Conditional Access Administrator (or higher)

  • Directory role management (PIM / role assignments): RoleManagement.ReadWrite.Directory + Privileged Role Administrator (or higher)

  • App registrations / service principals management: Application.ReadWrite.All (and/or related scopes) + Application Administrator (or higher)

So the pattern to remember is: admin consent + a tenant-wide scope can reduce "missing scope" failures, but every operation still has to pass (scope required by the endpoint) and (user allowed to do it).

How to secure Microsoft Graph Command Line Tools (step-by-step)

Step 0: Restrict who can sign into the app

Before you add more delegated permissions to Microsoft Graph Command Line Tools, decide who is allowed to authenticate with it. This is the difference between "admin-consenting a tool for the admin team" and "admin-consenting a tool for the whole tenant".

Two high-impact controls:

  • Require assignment for the enterprise application and only assign an admin group.

  • Conditional Access policy scoped to the app (MFA, compliant device, trusted location, etc.). Note that "Microsoft Graph Command Line Tools" is a Public Client (native app), which limits some CA controls (e.g., non-interactive flows); focusing on MFA and device compliance is key here.

When Assignment required? is enabled, only assigned users/groups can access the app, and users can't self-consent to it.

Suggested implementation steps:

  1. Create a security group (example: GraphCommandLineTools-Allowed).

  2. In Entra admin center -> Enterprise applications -> Microsoft Graph Command Line Tools:

    • Set Assignment required? to Yes.

    • Assign the GraphCommandLineTools-Allowed group under Users and groups.

  3. Create a Conditional Access policy targeting Microsoft Graph Command Line Tools that requires MFA (and, ideally, compliant/managed devices).

This scenario would also be a great candidate for an Entra Access Review to ensure the right users maintain access over time, or a PIM-enabled group for just-in-time access.

If you skip this step and you admin-consent tenant-wide delegated scopes, you're relying on "whoever can run PowerShell" as an access control boundary.

Step 1: Request the scope in PowerShell (so it's even eligible to be in the token)

Disconnect-MgGraph
Connect-MgGraph -Scopes "User.ReadWrite.All"
Get-MgContext | Select-Object -ExpandProperty Scopes

If the sign-in succeeds and Get-MgContext shows User.ReadWrite.All, great. If you get a consent/authorization error, move to Step 2.

You do this in the Entra admin center by granting the delegated permissions to the Enterprise application named "Microsoft Graph Command Line Tools".

High-level steps:

  1. Go to Entra admin center.

  2. Open Enterprise applications.

  3. Find and open Microsoft Graph Command Line Tools.

  4. Open the permissions/consent page (Permissions or Security > Permissions).

  5. Review the permissions the app is requesting, then grant admin consent if appropriate (example: User.ReadWrite.All, Group.ReadWrite.All).

  6. Choose Grant admin consent for your tenant (if required).

Security note: treat every delegated scope you add here as "available to every user who can sign into this app". That makes this an application hardening decision, not a script troubleshooting step.

Before you add anything new, it's worth doing a quick "permission hygiene" pass:

  • Review what Microsoft Graph delegated scopes are already granted to the app.

  • Remove anything you don't actively need.

  • Be especially cautious with tenant-wide write scopes (examples: Directory.ReadWrite.All, RoleManagement.ReadWrite.Directory, Policy.ReadWrite.ConditionalAccess, Application.ReadWrite.All).

In practice:

  • Use admin consent when the scope is high privilege (like directory-wide read/write) or when your tenant blocks user consent (for example, User.ReadWrite.All and Group.ReadWrite.All).

  • Use user consent only when (a) the scope is eligible for user consent and (b) your tenant allows it, and (c) you're comfortable with users granting that permission to the client app.

Even when user consent is technically possible, many organizations choose admin consent for anything beyond low-impact scopes so there's a clear approval trail.

Step 3: Reconnect and verify (don't skip this)

After consent is granted, reconnect and verify the granted scopes again:

Disconnect-MgGraph
Connect-MgGraph -Scopes "User.ReadWrite.All","Group.ReadWrite.All"
Get-MgContext | Select-Object -ExpandProperty Scopes

If the scopes show up and the user has the appropriate Entra role, your write operations should start behaving the way you expected.

Even if you lock down the enterprise app, it's still worth tightening tenant consent behavior so users can't freely grant new delegated permissions to other apps (or request high-privilege delegated permissions through ad-hoc tools).

Hardening moves:

  • Disable user consent, or limit it to verified publishers and low-impact permissions.

  • Enable the admin consent workflow so non-admin users can request access without teaching them to "click accept" on random consent prompts.

Example: why New-MgGroupMemberByRef is a good canary

Adding group members is a simple action with outsized impact. If you admin-consent group write scopes to Microsoft Graph Command Line Tools and you don't restrict who can use the app, you've made group membership changes possible from PowerShell for a much wider audience than "just the admin team".

Under the hood, this is the Microsoft Graph "add member" operation (POST /groups/{id}/members/$ref). In delegated scenarios, Graph requires an appropriate delegated scope (commonly GroupMember.ReadWrite.All) and also requires the signed-in user to be allowed to do the action (for example, a group owner or a supported Entra role). Role-assignable groups have additional requirements.

For the Graph PowerShell v1.0 cmdlet, the pattern is:

Connect-MgGraph -Scopes "GroupMember.ReadWrite.All"

$groupId = "<group-guid>"
# Note: This must be the Object ID (GUID) of the user/group, not the UPN/name
$memberId = "<user-or-group-object-guid>"

$body = @{
  "@odata.id" = "https://graph.microsoft.com/v1.0/directoryObjects/$memberId"
}

New-MgGroupMemberByRef -GroupId \(groupId -BodyParameter \)body

For the call to succeed, both must be true:

  • the delegated scope in the token (for example, GroupMember.ReadWrite.All), and

  • the signed-in user's allowed privileges (for example, being a group owner, or holding a supported Entra role)

What this looks like in Entra logs

When a user signs in with Connect-MgGraph using the default client app, you'll see a sign-in event for Microsoft Graph Command Line Tools in the sign-in logs, with Microsoft Graph as the target resource.

To find it:

  1. Entra admin center -> Monitoring & health -> Sign-in logs

  2. Filter Application = "Microsoft Graph Command Line Tools"

  3. Open the event and review the Conditional Access and Authentication Details tabs (useful to prove your app-specific CA policy is working)

When New-MgGroupMemberByRef succeeds, you should also see an entry in the audit logs for a group membership change (for example, an operation named "Add member to group"), showing:

  • Initiated by: the signed-in user

  • Target resources: the group and the member object

  • Additional details: look for identifiers for the group and the added member

To find it:

  1. Entra admin center -> Monitoring & health -> Audit logs

  2. Filter for group membership activities (start with "Add member to group")

  3. Open the event and confirm Initiated by and Target resources

Troubleshooting Graph PowerShell access errors

If you're troubleshooting a failure (or validating that your hardening changes are working), it helps to separate what enforces what: Entra ID authenticates the user and issues tokens, but Microsoft Graph authorizes each request at runtime. Tokens are necessary, but not sufficient.

When an action is denied, walk this checklist to figure out which gate blocked you:

  1. Right tenant and account? Check your active session details.

  2. Right scopes in the token? Run Get-MgContext. If the scope isn't there, Entra ID didn't issue it.

  3. Is the scope consented for the correct client? If you requested a scope and didn't get it, verify that consent was granted to the client app you're using (e.g., Microsoft Graph Command Line Tools).

  4. Does the user have the privileges? Even with the right scopes (scp) in the token, the user must hold the appropriate Entra roles, resource ownership, or Graph RBAC permissions. For example, Group.ReadWrite.All doesn't bypass a tenant policy that blocks standard users from creating groups.

  5. Is Conditional Access blocking you? If automation "suddenly" breaks or prompts for authentication before you even reach an API call, a CA policy might be requiring MFA or a compliant device for the client app.

Useful reset commands when you're stuck:

Get-MgContext | Format-List
Disconnect-MgGraph
Connect-MgGraph -Scopes "User.Read" -TenantId "<tenant-guid>"

How to figure out which scopes you actually need

Graph PowerShell cmdlets are wrappers over Microsoft Graph endpoints. The required delegated scopes come from the underlying API endpoint, not from the cmdlet name. To avoid guesswork:

  1. Identify the Microsoft Graph API endpoint you're calling.

  2. Check the Microsoft Graph permissions reference for that endpoint.

  3. Request the smallest scope set needed via Connect-MgGraph -Scopes ...

  4. Confirm what you actually received using Get-MgContext.

Security checklist (recap)

If you're turning a one-off command into a runbook, the risk profile changes. But even before you get to "automation", remember that Microsoft Graph Command Line Tools is a shared client app: whatever you admin-consent to it can become available to any user who can authenticate with it and request the scope.

A few guardrails help a lot:

  • Request the smallest scope set that gets the job done

  • Prefer short-lived sessions (connect, do the work, disconnect)

  • Avoid high-privilege scopes in shared automation accounts unless there's a clear business need and review process

  • Limit who can sign into the enterprise application (assignment required + group assignment where feasible)

  • Apply Conditional Access specifically to the app (MFA/compliant device/trusted locations)

  • Review and remove unused delegated permission grants from the app regularly

  • If you need tenant-wide permissions for automation, consider using a dedicated app registration instead of over-consenting Microsoft Graph Command Line Tools

An alternate approach: Why a dedicated Graph PowerShell client is safer

The safest pattern is usually not "admin-consent less to Microsoft Graph Command Line Tools." It's "stop using the shared client for privileged work."

Instead, create your own Entra app registration for Graph PowerShell sign-in and use that client ID with Connect-MgGraph. That gives you a separate enterprise application with its own consent history, Conditional Access targeting, sign-in logs, and assignment controls.

Why this matters:

  • Permission isolation: high-privilege delegated scopes are granted to your admin-only Graph client, not to the shared Microsoft Graph Command Line Tools app.

  • Access control: you can set Assignment required? = Yes and only assign a small admin group to the enterprise application.

  • Cleaner governance: reviews become easier because the app exists for one purpose instead of being a catch-all client used by anyone running Graph PowerShell.

  • Safer experimentation: if you need to test risky scopes like Directory.ReadWrite.All, you can do it in an isolated client without expanding the blast radius for every allowed user of the default app.

In practice, this means an ordinary user can keep using the default Graph PowerShell client for low-risk tasks, while privileged administrators use a separate dedicated client for elevated operations.

Conceptually, the flow looks like this:

Connect-MgGraph -ClientId "<admin-graph-client-app-id>" -TenantId "<tenant-id>"

At that point, the delegated token is being issued to your client application instead of Microsoft Graph Command Line Tools. So if Directory.ReadWrite.All is admin-consented to that dedicated client, only users who are allowed to use that client can request it.

This doesn't remove the need for Entra roles. Graph still evaluates both the token scopes and the signed-in user's privileges. What it does remove is the unnecessary exposure that comes from attaching powerful delegated permissions to a broadly available shared client.

Conclusion

When you use Connect-MgGraph with the default client app, you're authenticating through Microsoft Graph Command Line Tools, and delegated permissions are evaluated as "client app + user". That one idea explains most "why doesn't this work" moments - and most "how did this user get access to that?" moments too:

  • If the right scopes aren't granted (consented) to the client app, they won't appear in the token.

  • If the user doesn't have the necessary privileges (or policy blocks it), Graph will still deny the request.

So treat Microsoft Graph Command Line Tools like what it really is: a privileged administrative client. Keep its consent grants tight, and make sure only the right people (and devices) can use it. 🚀

#entra-id#powershell#identity-management

More from this blog

B

benroberts.io

26 posts

A blog for all things Azure! Whether you're a developer or IT pro, explore tips, trends, and hands-on guides to optimize and transform your workflow with Microsoft Azure's powerful capabilities.
